DTB4824RR | Delta Temperature Controllers

Name: DTB4824RR | Delta Temperature Controllers
Brand: Enervetic Automation Private Limited
Price: 3270.0 INR
Availability: InStock

Price 3270.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

DTB4824RR | Delta Temperature Controllers Specification

Overheating Protection
YES

Surface Finish
Matte

Operating Temperature
0 to 50C

Shape
Rectangular

IP Rating
IP66 (Front Panel)

Mounting Type
Panel Mount

Power Factor
High

Connector Type
Screw Terminal

Efficiency
High

Feature
Self-diagnosis, Auto-tuning, Fast Sampling

Insulation Material
Plastic

Humidity %
35-85% RH (non-condensing)

Product Type
Temperature Controller

Application
Industrial Automation, Process Control

Protection Level
IP66

Frequency (MHz)
50/60 Hz

Rated Voltage
100-240V AC

Energy Consumption
Low

Output Type
Relay, SSR Drive

Color
Black

Dimension (L*W*H)
48 x 24 x 75 mm

Weight
150g

Phase
Single Phase

Input Voltage
100-240VAC

Size
48 x 24 mm

No Of Poles
2

Material
Plastic, Metal

Connection Type
Screw Terminals

Input Type
Thermocouple (J, K, T, E, S, R, B, N), RTD (Pt100)

Control Output
Relay and SSR

Control Method
PID or ON/OFF

Accuracy
±0.5% of FS

Display
Dual 4-digit 7-segment LED

Storage Temperature
-20°C to 60°C

Sampling Rate
5 samples/second

Alarm Output
1 or 2 (configurable)

About DTB4824RR | Delta Temperature Controllers

Panel & Display

1/32 DIN size (48 24 mm).
Dual-line 7-segment LED display showing process value (PV) and setpoint (SV).

Power

Standard: AC 100240 V supply.
DC version (-D suffix): 24 VDC input option.

Inputs

Supports thermocouples, RTDs (Pt100/JPt100), and analog inputs (05 V, 010 V, 420 mA).

Outputs

Output 1: SPDT relay (250 VAC 5 A).
Output 2: SPDT relay (250 VAC 5 A).

Control Features

PID, ON/OFF, manual, and ramp/soak (program) control modes.
RS-485 serial communications with Modbus ASCII/RTU support.

Superior Performance and Versatility

The DTB4824RR controller features a broad input compatibility, handling a range of thermocouples and RTD sensors. With options for relay and SSR outputs, and selectable PID or ON/OFF control, it delivers precise temperature management for various industrial processes. Its high sampling rate and fast response make it a top choice for automation.

Robust Protection and Easy Integration

Engineered with an IP66-rated front panel and strong insulation materials, the DTB4824RR withstands harsh industrial environments. Panel mounting and screw terminal connections ensure simple installation and maintenance. Its auto-diagnosis and self-tuning functions further reduce downtime and enhance reliability in operation.

FAQ's of DTB4824RR | Delta Temperature Controllers:

Q: How do I configure the DTB4824RR temperature controller for different sensor types?

A: The DTB4824RR supports various thermocouples (J, K, T, E, S, R, B, N) and RTD (Pt100) sensors. Configuration is accomplished through panel setting menus on the dual LED display. Simply select the input type according to the connected sensor following the user manual.

Q: What are the main benefits of using the DTB4824RR in process control applications?

A: This controller offers high accuracy (0.5% FS), fast sampling (5 samples/second), reliable PID or ON/OFF control, and robust overheating protection. These features enable precise temperature management, increased process efficiency, and greater system reliability in industrial automation.

Q: When should I use PID versus ON/OFF control methods with this controller?

A: PID control is ideal for processes requiring stable, precise temperature regulation with minimal fluctuation, while ON/OFF control is suitable for applications where simple, threshold-based activation is sufficient. The DTB4824RR allows easy selection between the two modes to suit your specific process needs.

Q: Where is the DTB4824RR typically installed, and how is it connected?

A: This device is designed for panel mount installation, commonly found in industrial control panels. It connects using screw terminals, supporting easy wiring to sensors, power supply (100-240V AC), and control outputs (relay or SSR drive).

Q: What protection features does the DTB4824RR provide for industrial use?

A: The controller offers IP66-rated protection on the front panel, effective overheating protection, and operates safely in environments with 35-85% humidity and temperatures ranging from 0C to 50C. These features safeguard both the device and connected processes from common operational hazards.
